Three-phase 440/480 VAC
| CODE | TYPE | NOM. BATTERY VOLTAGE | OUTPUT CURRENT | OUTPUT CURRENT WUla |
RECOMMENDED BATTERIES CAPABILITIES |
| F8 BV.. | NG5 24-100 | 24 V | 100 A | - | 500-1000 AH |
| F8 CV.. | NG5 35-100 | 36 V | 100 A | - | 500-1000 AH |
| F8 ET.. | NG5 48-80 | 48 V | 80 A | 95 A | 400-800 AH |
| F8 EV | NG7 48-100 | 48 V | 100 A | - | 400-1000 AH |
| F8 HR | NG5 72-55 | 72 V | 55 A | 65 A | 275-550 AH |
| F8 HS | NG7 72-70 | 72 V | 70 A | 85 A | 280-700 AH |
| F8 HV | NG9 72-100 | 72 V | 100 A | - | 400-960 AH |
| F8 IQ | NG5 80-50 | 80 V | 50 A | 60 A | 250-500 AH |
| F8 IS | NG7 80-65 | 80 V | 80 A | 95 A | 320-780 AH |
| F8 IT | NG9 80-80 | 80 V | 80 A | 95 A | 325-650 AH |
| F8 LP | NG5 84-45 | 84 V | 45 A | 55 A | 225-450 AH |
| F8 MO | NG5 96-40 | 96 V | 40 A | 50 A | 200-400 AH |
| F8 PM | NG5 120-30 | 120 V | 30 A | 35 A | 150-300 AH |
Technical
Characteristics
Zivan battery chargers feature state-of-the-art high frequency
technology.
•
Adaptable to
every use and very flexible.
•
CE certified.
•
Metal case
base and ABS cover.
•
Coated
printed circuit boards.
•
ZIVAN
chargers are all microprocessor-controlled and internally protected
against overload, short circuit, incorrect connection
and voltage transients.
• Increased battery life and reduction of water usage.
• ZIVAN chargers operate at 85-90% efficency for maximum savings of electric power cost.
With the Thermal sensor option, the charger's output electronically compensates for temperatures ranging from 0° to 50°.
• Operating temperature from -20° to +50°.
• Weight and size are minimized.
